| XLITE-V4 specifications: |
24 |
| Recommended series cell |
13S to 24S |
| Recommended operating voltage |
24V to 104V |
| Minimum operating battery voltage |
15V |
| Cell voltage operating range |
2V to 5V |
| Abs. Max battery voltage |
120V |
| Max. continuous charging current |
20A** |
| Balancing current |
50mA @4.2V |
| Low power mode quiescent current |
|
| External NTC-temp |
2 channels |
| Operating temp. |
|
| Dimensions |
31.5mm X 90mm x 9mm |
| Connectors |
JST PH 2mm |
** Aluminum case required otherwise less than 10A
Description:
Charge only, Smart BMS compatible with the VESC ecosystem
Easy setup with VESC-tool mobile app
Isolated CAN bus & Bluetooth connectivity
Cell voltage, humidity, internal & up to 2 external temperature sensors, charge current, SoC, SoH, Wh, Ah, pack & charger voltages monitoring
XT30 connectors for battery & charger connection
Support N.O. momentary push button with LED
1 x I2C bus (support most SSD1306 displays & some other I2C devices)
2 extra outputs (for optional pre-discharge & discharge)see X-LITE SHIELD
Buzzer , Status LED, automatic wake-up & auto-shutdown
